CYLINDER HEAD FRONT

OIL PUMP FOR KTM 1290 SUPER DUKE R SPECIAL EDITION ABS 2016

IGNITION SYSTEM

Item numbers

O-RING 19, 00X3, 00 NBR

0770191015

1,26 £

Unit Price Incl. Tax

O-RING 30X2, 0 FPM

0770300020

3,06 £

Unit Price Incl. Tax

TAB WASHER DIN6799-RS 7, 0

0799070000

0,90 £

Unit Price Incl. Tax

OIL LEVEL AND TEMPERATURE SENSOR

61338085000

61338085200

148,26 £

Unit Price Incl. Tax

OIL JET 70 M5

60030063070

8,16 £

Unit Price Incl. Tax

OIL SCREEN BUSHING 08

61238017000

7,38 £

Unit Price Incl. Tax

OIL SCREEN CMPL.

61238021100

61238021200

17,52 £

Unit Price Incl. Tax

OIL FILTER

61338015100

61338015200

11,88 £

Unit Price Incl. Tax

O-RING 14, 00X2, 00

0770140200

1,26 £

Unit Price Incl. Tax

OIL FILLER CAP M24X3 WITH O-R

58030120000

79430020033

9,84 £

Unit Price Incl. Tax

O-RING 12, 5X1, 5 NBR

0770125015

1,26 £

Unit Price Incl. Tax

O-RING 17, 00X2, 00

0770170200

1,26 £

Unit Price Incl. Tax

OIL INJECTION TUBE CPL. 08

61230065000

19,74 £

Unit Price Incl. Tax

O-RING 10.00X1.00 NBR70

0770010010

1,26 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X25 TX30

0025060256

1,74 £

Unit Price Incl. Tax

RETAINING WASHER DIN 6799 - 8

0799080000

0,90 £

Unit Price Incl. Tax

WASHER 10X16X0.5

60038007010

2,70 £

Unit Price Incl. Tax

OIL PUMP GEAR 24Z

60038001224

60038001324

42,60 £

Unit Price Incl. Tax

NEEDLE ROLLER NRB 4X15.8 G2

0402041580

1,44 £

Unit Price Incl. Tax

PRESSURE PUMP COVER CPL.

61238009144

32,46 £

Unit Price Incl. Tax

CONTROL PISTON

60038028000

60038128000

8,40 £

Unit Price Incl. Tax

SHIM

50337073000

3,06 £

Unit Price Incl. Tax

CONTROL SPRING

61238026000

6,72 £

Unit Price Incl. Tax

ROTOR-SET 19MM 03

60038009000

48,06 £

Unit Price Incl. Tax

OIL PUMP SHAFT 08

61238002000

28,02 £

Unit Price Incl. Tax

ROTOR SET 22MM

61238011100

48,06 £

Unit Price Incl. Tax

EATON PUMP SET 30MM

61238010100

48,06 £

Unit Price Incl. Tax

MOLDED RING SUCTION PUMP COVER

61238008150

13,92 £

Unit Price Incl. Tax

SUCTION PUMP COVER

61238008200

27,66 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0025060206

1,74 £

Unit Price Incl. Tax

NEEDLE ROLLER DIN 5402 5X9.8

0402050980

1,44 £

Unit Price Incl. Tax

MOLDED RING

61238051000

3,90 £

Unit Price Incl. Tax

OIL COOLER

6923805000033

69238150000C1

254,46 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X50 TX30

0025060506

2,04 £

Unit Price Incl. Tax

BUSHING

61238052000

3,48 £

Unit Price Incl. Tax

O-RING 12X2 VITON GREEN

0770012021

2,58 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X20

0025080206

2,88 £

Unit Price Incl. Tax

OILFILTER SERVICE KIT

00050000068

38,76 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
