GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM 1290 SUPER DUKE R SPECIAL EDITION ABS 2016

WATERPUMP

Item numbers

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

4,20 £

Unit Price Incl. Tax

SHIFT SHAFT CPL.

61234005333

129,72 £

Unit Price Incl. Tax

TENSIONING SPRING 0, 8MM

56534013100

2,04 £

Unit Price Incl. Tax

RADIAL SHAFT SEAL 14X24X6 B

0760142460

4,26 £

Unit Price Incl. Tax

RETURNSPRING 2MM

61234014000

6,12 £

Unit Price Incl. Tax

SPRING GUIDE

54634020000

4,86 £

Unit Price Incl. Tax

STOP DISK 14X30X1

54634050000

3,78 £

Unit Price Incl. Tax

PRESSURE SPRING 0, 9MM

58038023200

5,64 £

Unit Price Incl. Tax

SHIFT RAIL 11, 8X105MM

59034020000

14,70 £

Unit Price Incl. Tax

SHIFTING ROLLER 6X8X5, 2

50334018100

3,84 £

Unit Price Incl. Tax

SHIFT FORK 2-3 GEAR

61234002100

94,44 £

Unit Price Incl. Tax

SHIFTING FORK 08

61234001000

94,44 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0024060206

1,74 £

Unit Price Incl. Tax

LOCKING LEVER CPL. 07

75034024044

26,46 £

Unit Price Incl. Tax

SLEEVE FOR LOCKING LEVER 07

75034052000

5,40 £

Unit Price Incl. Tax

SPRING - LOCKING LEVER

61234023000

5,34 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X30 12.9

0912060309

1,50 £

Unit Price Incl. Tax

SHIFTING ARRESTOR CPL.

61234015444

61234015500

68,16 £

Unit Price Incl. Tax

BALL BEARING 61805 C3

0625618050

14,82 £

Unit Price Incl. Tax

SHIFT FORK 5-6 GEAR

61234003200

94,44 £

Unit Price Incl. Tax

GROOVED BALL BEARING 6808 JRC3

0625068080

14,82 £

Unit Price Incl. Tax

SHIFTING DRUM CPL.

60334012100

128,10 £

Unit Price Incl. Tax

O-RING 24.00X2.50 VITON

07700240251

2,58 £

Unit Price Incl. Tax

CYL. SCREW DIN6912 M5X16 8.8

0984050163S

1,50 £

Unit Price Incl. Tax

GEAR-POSITION SENSOR

60211023100

135,78 £

Unit Price Incl. Tax

SHIFT LEVER CPL. 16

6133403104433S

6133403114433S

103,68 £

Unit Price Incl. Tax

WASHER DIN0125-A 5, 3

0125050003

Contact

STEEL WASHER 6, 4X17X3

50232050001

1,74 £

Unit Price Incl. Tax

PAIR OF WASHERS M 6 NORDLOCK

50233041000

2,76 £

Unit Price Incl. Tax

RUBBER FOR SHIFT LEVER 05

61034035000

6,60 £

Unit Price Incl. Tax

SPECIAL WASHER D=23X7, 2MM

61334041000

5,88 £

Unit Price Incl. Tax

AH-COLLAR SCREW M8X30 ISA45

0035080306S

3,36 £

Unit Price Incl. Tax

GROOVED BALL BEAR. 608 2RS C3

0625006087

6,36 £

Unit Price Incl. Tax

WASHER DIN 125 A -8.4

0125080003

0,90 £

Unit Price Incl. Tax

SPECIAL WASHER D=20X6, 8MM

61334040000

5,88 £

Unit Price Incl. Tax

COUNTER-SUNK SCREW ISA45 M8X26

0019080266S

3,36 £

Unit Price Incl. Tax

RELAY LEVER BLACK 07

6103403000033S

68,58 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0025060206S

2,04 £

Unit Price Incl. Tax

SHIFT ROD CPL.

61334036044

59,58 £

Unit Price Incl. Tax

STEP PLATE SHIFTING LEVER

69034032000

23,88 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X35

0912060353

1,26 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X16 TX30 SL

0025060166S

2,04 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
