GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM 890 DUKE R 2020

WATERPUMP

Item numbers

HH COLLAR SCREW M6X15 TX30

0024060156S

2,04 £

Unit Price Incl. Tax

SHIFT LOCKER CPL.

63534015000

61,98 £

Unit Price Incl. Tax

DEEP GROOVE BALL BEARING 6807

0625068070

10,62 £

Unit Price Incl. Tax

INT. TORX FLAT HEAD M5X12 T25

0019050121S

2,04 £

Unit Price Incl. Tax

BEARING RETAINING BRACKET

63534011100

63534011200

6,72 £

Unit Price Incl. Tax

SHIFT DRUM 6G

63534012001

116,40 £

Unit Price Incl. Tax

DEEP GROOVE BALL BEARING 6806 C3
DEEP GROOVE BALL BEARING 6806

0625068060

10,62 £

Unit Price Incl. Tax

MAGNET HOLDER CPL.

79234012020

32,40 £

Unit Price Incl. Tax

GEAR POSITION SENSOR

79211023000

98,10 £

Unit Price Incl. Tax

HH COLLAR SCREW M5X12 TX30

0025050126

1,74 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X16 TX30 SL

0025060166S

2,04 £

Unit Price Incl. Tax

BEARING RETAINING PLATE

63533022000

13,50 £

Unit Price Incl. Tax

SHIFT SHAFT CPL.

63534005033

117,90 £

Unit Price Incl. Tax

TENSIONING SPRING 0, 8MM

56534013100

2,04 £

Unit Price Incl. Tax

SPRING GUIDE

54634020000

4,86 £

Unit Price Incl. Tax

RETURNSPRING 2MM

61234014000

6,12 £

Unit Price Incl. Tax

STOP DISK 14X30X1

54634050000

3,78 £

Unit Price Incl. Tax

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

4,20 £

Unit Price Incl. Tax

RADIAL SHAFT SEAL 14X24X6 B

0760142460

4,26 £

Unit Price Incl. Tax

DOWEL PIN DIN 7 A1 2.5M6X24

0007025241

1,26 £

Unit Price Incl. Tax

MAGNET HOLDER

63534050000

30,24 £

Unit Price Incl. Tax

VALVE SPRING

63534050010

0740001502500

5,40 £

Unit Price Incl. Tax

THRUST WASHER DIN 988 14X20X0.5
THRUST WASHER DIN 988 14X20X0.

0988142005

0,90 £

Unit Price Incl. Tax

RETAINING RING DIN 471 14X1

0471140100

1,20 £

Unit Price Incl. Tax

PULL ROD

6413403000033

31,20 £

Unit Price Incl. Tax

PAIR NORDLOCK WASHER M6

50233041500

2,76 £

Unit Price Incl. Tax

SHIFT ASSISTANT SENSOR

63534051000

139,32 £

Unit Price Incl. Tax

CYLIND. SCR. DIN6912 M5X12 8.8

0984050123S

1,50 £

Unit Price Incl. Tax

DETENT ARM CPL.

63534024000

26,46 £

Unit Price Incl. Tax

STEP WASHER

63534052000

2,82 £

Unit Price Incl. Tax

DETENT ARM SPRING

63634023000

4,86 £

Unit Price Incl. Tax

SHIFT FORK 5-6 GEAR

63534002000

85,86 £

Unit Price Incl. Tax

SHIFT FORK

63534001100

85,86 £

Unit Price Incl. Tax

SHIFT FORK SHAFT

75034019100

18,72 £

Unit Price Incl. Tax

NEEDLE ROLLER D8X20

0402080200

1,44 £

Unit Price Incl. Tax

SHIFTER ROD CPL.

64134036044

54,18 £

Unit Price Incl. Tax

OVAL HEAD SCREW ISR M6X20-A2-70-MK
OVAL HEAD SCREW ISR M6X20-A2-7

0738060205S

1,50 £

Unit Price Incl. Tax

RND. HD. SCR. TX M6X16 A2-70 S

0738060165S

1,50 £

Unit Price Incl. Tax

COUNTER-SUNK SCREW ISA45 M8X30

0019080306S

3,36 £

Unit Price Incl. Tax

FASSON DISC D=23X5

64134031020

5,40 £

Unit Price Incl. Tax

GEAR LEVER KPL. BLACK

6413403104433

94,20 £

Unit Price Incl. Tax

RUBBER FOR SHIFT LEVER 05

61034035000

6,60 £

Unit Price Incl. Tax

GEAR LEVER

69034032100

23,88 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X45

0912060453

1,50 £

Unit Price Incl. Tax

GROOVED BALL BEAR. 608 2RS C3

0625006087

6,36 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your KTM 890 DUKE R of 2020. Let us know if you have any questions.
