OIL PUMP FOR KTM 790 ADVENTURE ORANGE - CKD 2020

IGNITION SYSTEM

Item numbers

GEARBOX LUBRICATION PIPE CMPL.

63530065000

30,24 £

Unit Price Incl. Tax

O-RING 10.00X1.00 NBR70

0770010010

1,26 £

Unit Price Incl. Tax

GASKET WITH SUPPORT SHEET

63538051000

30,54 £

Unit Price Incl. Tax

OIL-WATER-HEATER EXCHANGER

63538050000

197,04 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0025060206S

2,04 £

Unit Price Incl. Tax

OIL LINE

63538035000

65,10 £

Unit Price Incl. Tax

PRESSURE PLATE

63530086010

15,30 £

Unit Price Incl. Tax

INT. TORX FLAT HEAD M5X12 T25

0019050121S

2,04 £

Unit Price Incl. Tax

SHCS ISO 14580 M6X16 SL

014580060166S

1,50 £

Unit Price Incl. Tax

BEARING BOLT

63638003000

11,16 £

Unit Price Incl. Tax

OIL PUMP IDLER WHEEL 22 TEETH CPL.
OIL PUMP IDLER WHEEL 22 TEETH

63538001022

34,32 £

Unit Price Incl. Tax

RETAINING WASHER DIN 6799 - 8

0799080000

0,90 £

Unit Price Incl. Tax

WASHER 10X16X0.5

60038007010

2,70 £

Unit Price Incl. Tax

OIL PUMP GEAR 24Z

60038001224

60038001324

42,60 £

Unit Price Incl. Tax

OIL PUMP COVER PLATE

63538008050

21,84 £

Unit Price Incl. Tax

ROTOR-SET PRESSURE PUMP 03

60038011100

60038011000

48,06 £

Unit Price Incl. Tax

OIL PUMP SHAFT

63538002000

25,44 £

Unit Price Incl. Tax

NEEDLE ROLLER NRB 4X15.8 G2

0402041580

1,44 £

Unit Price Incl. Tax

NEEDLE ROLLER DIN 5402 5X9.8

0402050980

1,44 £

Unit Price Incl. Tax

O-RING 12, 00X2, 00 NBR 70

0770120020

1,26 £

Unit Price Incl. Tax

OIL PUMPHOUSING

63538012000

64,32 £

Unit Price Incl. Tax

O-RING 14, 00X2, 00

0770140200

1,26 £

Unit Price Incl. Tax

O-RING 20X2 VITON

0770020020

2,58 £

Unit Price Incl. Tax

CONTROL PISTON

60038128000

8,40 £

Unit Price Incl. Tax

OIL PRESSURE SPRING

63538026000

6,12 £

Unit Price Incl. Tax

SHIM

50337073000

3,06 £

Unit Price Incl. Tax

EATON PUMP SET 30MM

61238010100

48,06 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X25 TX30

0025060256

1,74 £

Unit Price Incl. Tax

OIL SUMP GASKET

63530086000

26,58 £

Unit Price Incl. Tax

OIL PAN

6353008500024

150,90 £

Unit Price Incl. Tax

OIL SCREEN CMPL.

61238021100

61238021200

17,52 £

Unit Price Incl. Tax

O-RING 12, 5X1, 5 NBR

0770125015

1,26 £

Unit Price Incl. Tax

O-RING 17, 00X2, 00

0770170200

1,26 £

Unit Price Incl. Tax

OIL FILTER

61338015200

11,88 £

Unit Price Incl. Tax

O-RING 39, 34X2, 62

07700390261

1,50 £

Unit Price Incl. Tax

OIL FILTER COVER

75038041200

21,84 £

Unit Price Incl. Tax

HH COLLAR SCREW M5X16 TX30

0025050166

1,74 £

Unit Price Incl. Tax

DOWEL, 6X8X11.5

59030023000

59030023100

2,34 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X35 TX30

0025060356

1,74 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X30 TX30

0025060306

1,74 £

Unit Price Incl. Tax

O-RING 6X2.5

0770060025

2,58 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X16 TX40 SL

0025080166S

3,36 £

Unit Price Incl. Tax

O-RING 7X2, 50 HNBR

0770070025

2,58 £

Unit Price Incl. Tax

OILFILTER SERVICE KIT

00050000068

38,76 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the OIL PUMP of your KTM 790 ADVENTURE ORANGE - CKD of 2020. Let us know if you have any questions.
