FRAME FOR KTM 690 ENDURO R 2022

ENGINE GUARD

Item numbers

FRAME 761 ELEC.ORANGE
FRAME 761UA ELEC.ORANGE

76103001000EB

1 763,10 £

Unit Price Incl. Tax

FRAME COVER LEFT

76903092000

34,50 £

Unit Price Incl. Tax

FRONT FOOTPEG BRACKET LEFT CMPL.
FRONT FOOTPEG BRACKET LEFT CMP

7690303804401

140,28 £

Unit Price Incl. Tax

FOOTPEG BRACKET RIGHT CMPL.

7690303904401

140,28 £

Unit Price Incl. Tax

FOOTREST L/S + R/S CPL. 09

78003040033

85,08 £

Unit Price Incl. Tax

FOOTREST L/S 08

78003040050

33,84 £

Unit Price Incl. Tax

FOOTREST R/S 08

78003041050

33,84 £

Unit Price Incl. Tax

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

7,98 £

Unit Price Incl. Tax

FOOTREST SPRING L/S & R/S

54603041000

3,72 £

Unit Price Incl. Tax

WASHER DIN 125 A 10.5

0125100003

0,90 £

Unit Price Incl. Tax

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

0,90 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X45 TX40

0025080456

2,88 £

Unit Price Incl. Tax

HEEL PROTECTOR, LEFT

76903038050

8,64 £

Unit Price Incl. Tax

HEEL PROTECTOR, RIGHT

76903039050

8,64 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X12 TX40

0025080126

2,88 £

Unit Price Incl. Tax

REAR FOOTPEG BRACKET LEFT

7690304800001

124,26 £

Unit Price Incl. Tax

REAR FOOTPEG BRACKET RIGHT

7690304900001

124,26 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X16 TX40

0025080166

2,88 £

Unit Price Incl. Tax

FOOTREST CPL. L/S REAR 03

60003050000

58,38 £

Unit Price Incl. Tax

FOOTREST CPL. R/S REAR 03

60003051000

58,38 £

Unit Price Incl. Tax

BOLT FOR FOOTREST REAR 03

60003044000

11,10 £

Unit Price Incl. Tax

ENGAGE PANEL FOOTREST L/S 03

60003152000

6,18 £

Unit Price Incl. Tax

ENGAGE PANEL FOOTREST R/S 03

60003052000

6,18 £

Unit Price Incl. Tax

RETAINING WASHER DIN 6799 - 6

0799060003

0,90 £

Unit Price Incl. Tax

FRAME COVER RIGHT

76903086000

23,88 £

Unit Price Incl. Tax

SCREW FOR PLASTIC 50X18 T20

0081250181

1,74 £

Unit Price Incl. Tax

SPECIAL SCREW M5X12

69008021160

3,06 £

Unit Price Incl. Tax

OIL SEPARATOR VENT

76930088030

25,62 £

Unit Price Incl. Tax

CLIP NUT M5

69008021080

2,82 £

Unit Price Incl. Tax

ANGLE CONNECTOR LC8 03

60038082000

17,88 £

Unit Price Incl. Tax

O-RING 8X2 SILICONE

0770080020

1,26 £

Unit Price Incl. Tax

SHCS M8X20 TX45

0035080206S

3,36 £

Unit Price Incl. Tax

CHAIN SLID. GUARD 08

76504067000

9,90 £

Unit Price Incl. Tax

CHAIN GUARD CPL. 08

76530060044

18,84 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X35 TX40

0025080356

2,88 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X40 TX30

0025060406

1,74 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X12 TX30

0025060126

1,74 £

Unit Price Incl. Tax

CONTACT WASHER M6 VSV-K6

58411098100

2,34 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X10 TX30

0024060106

1,74 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X8 TX30

0025060086

1,74 £

Unit Price Incl. Tax

CLAMP RSGU 15/12

49007439000

2,10 £

Unit Price Incl. Tax

HH COLLAR SCREW M5X12 TX30

0025050126

1,74 £

Unit Price Incl. Tax

SPECIAL SCREW M6X14

69008021040

3,06 £

Unit Price Incl. Tax

SEAT HOLDER

76907026000

5,10 £

Unit Price Incl. Tax

ENGINE SUPPORT L/S BLACK

7650300500033

107,16 £

Unit Price Incl. Tax

ENGINE SUPPORT R/S BLACK

7650300600033

107,16 £

Unit Price Incl. Tax

SHCS M10X24 TX45

0035100249

4,50 £

Unit Price Incl. Tax

SPECIAL SCREW M10X115 ISK8 07

75003015000

10,74 £

Unit Price Incl. Tax

SPECIAL SCREW M10X152 ISK8 07

75003014000

12,12 £

Unit Price Incl. Tax

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

2,76 £

Unit Price Incl. Tax

SELF LOCKING NUT M10 CU WS=14

54310086100

2,10 £

Unit Price Incl. Tax

CHAIN SLIDING BELOW 08-13

76504067010

14,52 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME of your KTM 690 ENDURO R of 2022. Let us know if you have any questions.
