GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM 690 DUKE ORANGE 2017

GEAR SHIFT LEVER

Item numbers

SHIFT FORK F. SLIDINGGEAR 5 12

75034002100

85,86 £

Unit Price Incl. Tax

SHIFT FORK F. SLIDINGG. 3/4 12

75034001100

85,86 £

Unit Price Incl. Tax

SHIFT FORK F. SLIDINGGEAR 6 12

75034003100

85,86 £

Unit Price Incl. Tax

NEEDLE ROLLER DIN5402 6X14, 8

0402061480

1,44 £

Unit Price Incl. Tax

SHIFT FORK SHAFT

75034019000

75034019100

18,72 £

Unit Price Incl. Tax

SHIFT SHAFT ASSY

75034005133

117,90 £

Unit Price Incl. Tax

TENSIONING SPRING 0, 8MM

56534013100

2,04 £

Unit Price Incl. Tax

SPRING GUIDE

54634020000

4,86 £

Unit Price Incl. Tax

RETURN SPRING 2, 2MM '95

54634014100

4,44 £

Unit Price Incl. Tax

STOP DISK 14X30X1, 5 STEEL

75034050000

4,68 £

Unit Price Incl. Tax

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

4,20 £

Unit Price Incl. Tax

SHAFT SEAL RING 14X24X6B VITON

0760142461

7,56 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0024060206

1,74 £

Unit Price Incl. Tax

LOCKING LEVER CPL. 07

75034024044

26,46 £

Unit Price Incl. Tax

SLEEVE FOR LOCKING LEVER 07

75034052000

5,40 £

Unit Price Incl. Tax

ARRESTING LEVER SPRING 03

60034023000

5,34 £

Unit Price Incl. Tax

AH SCREW DIN6912 M6X30 8.8

0012060303

1,26 £

Unit Price Incl. Tax

SHIFT DRUM LOCATING CPL. 07 (0912060309S, 60034023000, 61434024000, 76834115001, 76834215000)
SHIFT DRUM LOCATING CPL. 07

75034015000

26,52 £

Unit Price Incl. Tax

BALL BEARING 61805 C3

0625618050

14,82 £

Unit Price Incl. Tax

SHIFTING DRUM CPL.

76634012044

76634012144

133,68 £

Unit Price Incl. Tax

NEEDLE BEAR HK3512 35X42X12

0618354212

7,56 £

Unit Price Incl. Tax

MAGNET HOLDER CPL.

79234012020

32,40 £

Unit Price Incl. Tax

SPRING F. SHIFTING SHAFT CPL.

75034007044

6,72 £

Unit Price Incl. Tax

PAN HEAD SCREW M5X10 TX25

073800501002

1,26 £

Unit Price Incl. Tax

GEAR POSITION SENSOR

60411023000

153,24 £

Unit Price Incl. Tax

CYL. SCREW DIN6912 M5X14 8.8

0984050143S

1,50 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
