FRONT FORK / TRIPLE CLAMP FOR KTM 690 DUKE ORANGE 2009

FRONT FORK (PARTS)

Item numbers

FORK KTM 690 DUKE 2009

14187E0901

1 934,46 £

Unit Price Incl. Tax

AH SCREW DIN6912-M10X60

0012100603

3,84 £

Unit Price Incl. Tax

HH COLLAR SCREW M8X30

0025080306

2,88 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 8X30

0912080303

2,04 £

Unit Price Incl. Tax

HH COLLAR SCREW M5X20 TX30

0025050206

1,74 £

Unit Price Incl. Tax

SELF LOCKING NUT DIN0985-M 5

0985050003

1,26 £

Unit Price Incl. Tax

CLAMP BRAKE HOSE 07

75001070000

12,48 £

Unit Price Incl. Tax

BOTTOM TRIPLE CLAMP CPL. 07

7500103203201S

309,54 £

Unit Price Incl. Tax

FORK TUBE LC8 ADV 03

60001033000

94,86 £

Unit Price Incl. Tax

TOP TRIPLE CLAMP 54MM 07

7500103403201S

254,28 £

Unit Price Incl. Tax

STEERING HEAD SCREW M20X1.5 SW=27

54801036000

54801036300

13,50 £

Unit Price Incl. Tax

HANDLEBAR CLAMP 28MM 07

5900103830001S

23,88 £

Unit Price Incl. Tax

HANDLEBAR MOUNT 28?MM 07

5900103920001S

5900103930001

57,48 £

Unit Price Incl. Tax

WASHER 10.5X32X2

56401042000

4,74 £

Unit Price Incl. Tax

RUBBER BUSHING

56401040000

4,74 £

Unit Price Incl. Tax

SELF LOCK.NUT DIN0982-M10 HIGH

0982100003

1,98 £

Unit Price Incl. Tax

SPACER TUBE 10.2X12X38

61001041000

5,58 £

Unit Price Incl. Tax

TAPERED ROLLER BEARING CPL. 06

54201081100

Contact

O-RING SUPPORT W. SEALING LIP

54601084200

77701084000

13,50 £

Unit Price Incl. Tax

STEARING HEAD GASKET TOP

54601184000

4,26 £

Unit Price Incl. Tax

STEERING HEAD COVER 05

61001086000

9,48 £

Unit Price Incl. Tax

BUSHING MUD FLAP 07

75001094010

6,18 £

Unit Price Incl. Tax

AH SCREW DIN6912 M6X12

0012060123

Contact

FENDER FRONT BLACK MET. 08

7560801000040A

156,72 £

Unit Price Incl. Tax

STEARING HEAD REPAIR KIT

00050000930

54201081144

51,36 £

Unit Price Incl. Tax

HANDLEBAR SUPPORT KIT

00050000922

112,02 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
