SHOCK ABSORBER (PARTS)

SWINGARM FOR KTM 530 XC-W 2009

EXHAUST

(2) 78004030244

SWINGARM CPL. '11
SWING ARM CPL. 08

(3) 77304066000

CHAIN SLIDING PROTECTION

(4) 77304066150

CHAIN SLIDER BUSHING

(5) 0009050106

EJOT SPIRAL SCREW SF M5X10-K
SPECIAL SCREW M 5,0X10

(6) 77313047000

BRAKE HOSE GUIDE LOWER 07

(7) 59009062013

SPECIAL SCREW M6X13 WS=8 10.9

(8) 54804034000

BUCKET F. SHAFT SEAL RING 03

(8) 54804034000

BUCKET F. SHAFT SEAL RING 03

(9) 0760253270

RADIAL SHAFT SEAL 25X32X7

(9) 0760253270

RADIAL SHAFT SEAL 25X32X7

(9) 0760253270

RADIAL SHAFT SEAL 25X32X7

(9) 0760253270

RADIAL SHAFT SEAL 25X32X7

(10) 59404032000

BEARING SLEEVE 17X22X38,7 03

(11) 0618222812

NEEDLEBEAR HK2212V 22/28/12 MB
NEEDLE BEARING HK2212V

(12) 54603036000

STOP DISK 22,2X31,7X1

(12) 54603036000

STOP DISK 22,2X31,7X1

(14) 77304070310

CHAIN GUIDE KIT REAR 08-14
CHAIN GUIDE REAR CPL. 07

(15) 59009062019

SPECIAL SCREW M6X19 WS=8 10.9

(16) 0025060456

HH COLLAR SCREW M6X45 TX30

(17) 77304070030

INSERTION NUT F. CHAIN GUIDE

(18) 50304090144

PIVOT BEARING+BUSH. PDS '11
PIVOT BEARING+BUSH. PDS '99

(19) 50329000044

TOOL BEARING MOUNTING PDS

(24) 55009086000

PLUG SFL13

(24) 55009086000

PLUG SFL13

(25) 77304037000

SWINGARM BOLT M16X1,5 07

(26) 54804038000

SELF LOCK.NUT M16X1,5 WS=19 03

(27) 58404041100

CLOSING COVER ROUND 03

(28) 77304066010

CHAIN GUARD CPL. 07-11

(29) 54603055051

PRESS IN NUT M6 STEEL ZINC

(98) 77304070310

CHAIN GUIDE KIT REAR 08-14

(99) 54804230010

SWINGARM REP. KIT
SWINGARM-REPAIR KIT 05-14

	Part number	Description	Qty
# 2	78004030144	SWINGARM CPL. '11 SWING ARM CPL. 08	Contact	0,00 £
# 3	77304066000	CHAIN SLIDING PROTECTION	18,60 £
# 4	77304066050 77304066150	CHAIN SLIDER BUSHING	3,30 £
# 5	0009050103 0009050106	EJOT SPIRAL SCREW SF M5X10-K SPECIAL SCREW M 5, 0X10	1,62 £
# 6	77313047000	BRAKE HOSE GUIDE LOWER 07	6,30 £
# 7	59009062013	SPECIAL SCREW M6X13 WS=8 10.9	1,56 £
# 8	54804034000	BUCKET F. SHAFT SEAL RING 03	8,58 £
# 9	0760253270	RADIAL SHAFT SEAL 25X32X7	4,92 £
# 10	59404032000	BEARING SLEEVE 17X22X38, 7 03	9,90 £
# 11	59004031100 0618222812	NEEDLEBEAR HK2212V 22/28/12 MB NEEDLE BEARING HK2212V	7,56 £
# 12	54603036000	STOP DISK 22, 2X31, 7X1	2,34 £
# 14	77304070000 77304070310	CHAIN GUIDE KIT REAR 08-14 CHAIN GUIDE REAR CPL. 07	43,50 £
# 15	59009062019	SPECIAL SCREW M6X19 WS=8 10.9	1,80 £
# 16	0025060456	HH COLLAR SCREW M6X45 TX30	1,62 £
# 17	77304070030	INSERTION NUT F. CHAIN GUIDE	8,58 £
# 18	50304090044 50304090144	PIVOT BEARING+BUSH. PDS '11 PIVOT BEARING+BUSH. PDS '99	39,18 £
# 19	50329000044	TOOL BEARING MOUNTING PDS	Contact	0,00 £
# 24	55009086000	PLUG SFL13	1,56 £
# 25	77304037000	SWINGARM BOLT M16X1, 5 07	60,00 £
# 26	54804038000	SELF LOCK.NUT M16X1, 5 WS=19 03	9,90 £
# 27	58404041100	CLOSING COVER ROUND 03	3,30 £
# 28	77304066010	CHAIN GUARD CPL. 07-11	25,38 £
# 29	54603055051	PRESS IN NUT M6 STEEL ZINC	2,34 £
# 98	77304070310	CHAIN GUIDE KIT REAR 08-14	43,50 £
# 99	59404230110 54804230010	SWINGARM REP. KIT SWINGARM-REPAIR KIT 05-14	65,10 £

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
