FRONT FORK / TRIPLE CLAMP FOR KTM 50 SX PRO JUNIOR LC 2003

HANDLEBAR / CONTROLS

FRONT FORK / TRIPLE CLAMP for KTM 50 SX PRO JUNIOR LC 2003
1
(1)  45101000444
FORK CPL. SX JUN MARZ. 2002
5
(5)  7501476A
TOP FORK PLATE
6
(6)  0912080303
AH SCREW DIN0912-M 8X30
6
(6)  0912080303
AH SCREW DIN0912-M 8X30
6
(6)  0912080303
AH SCREW DIN0912-M 8X30
8
(8)  7504212AC
PLUG CAP
9
(9)  7528010
O-RING
11
(11)  7518031
PRE LOAD BUSH L=55MM 2002
12
(12)  75141169
SPRING 2N/MM
(12)  75141214
SPRING 2,5N/MM
13
(13)  7533297
DUST SEAL
13
(13)  7533297
DUST SEAL
13
(13)  7533297
DUST SEAL
14
(14)  7523264
STOP RING
14
(14)  7523264
STOP RING
14
(14)  7523264
STOP RING
15
(15)  7528230
OIL SEAL 32/42/6,5-9,5
15
(15)  7528230
OIL SEAL 32/42/6,5-9,5
15
(15)  7528230
OIL SEAL 32/42/6,5-9,5
16
(16)  7522166AA
WASHER D42X32,5X1,5
16
(16)  7522166AA
WASHER D42X32,5X1,5
16
(16)  7522166AA
WASHER D42X32,5X1,5
17
(17)  7524157
PISTON RING D32
18
(18)  7803936/A
PISTON ROD REBOUND JUNIOR 02
(18)  7803938A
PISTON ROD COMPRESSION JUN. 02
19
(19)  75141015
REBOUND SPRING
20
(20)  75031570A
SLIDER L/S 50 LC 2002
20
(20)  75031570A
SLIDER L/S 50 LC 2002
21
(21)  75031570A/R
SLIDER CPL. L/S 50LC 2002
22
(22)  7522225
WASHER 14X8X1,5
25
(25)  77051124
BOT. FORK PLATE CPL. MINI/JUN
26
(26)  7708247/R
FORK TUBE R/S MINI/JUN. 02
27
(27)  7708248/R
FORK TUBE L/S MINI/JUN. 02
28
(28)  7512068
FOOT BUFFER
29
(29)  75031571A
SLIDER R/S 50 LC 2002
29
(29)  75031571A
SLIDER R/S 50 LC 2002
31
(31)  75031571A/R
SLIDER CPL. R/S 50LC 2002
34
(34)  50301036000
STEER.HEAD SCREW M20X1,5 WS=27
35
(35)  45101081100
STEER.STEM B.CPL.50 SXR 2003 (45101036000, 45101081200)
STEER.STEM B.CPL.50 SXR 2003
36
(36)  0025080306
HH COLLAR SCREW M8X30
HH COLLAR SCREW M 8X30 WS=10
36
(36)  0025080306
HH COLLAR SCREW M8X30
HH COLLAR SCREW M 8X30 WS=10
37
(37)  0032100256S
AH-COLLAR SCREW M10X25 ISA45
AH SCREW DIN6912-M10X25,10.9
37
(37)  0032100256S
AH-COLLAR SCREW M10X25 ISA45
AH SCREW DIN6912-M10X25,10.9
38
(38)  50301038000
HANDLEBAR CLAMP D=22MM 2001
38
(38)  50301038000
HANDLEBAR CLAMP D=22MM 2001
39
(39)  45101039000
HANDLEBAR SUPPORT D=22MM 2001
40
(40)  7547325
STICKER LEFT SIDE MARZOCCHI
41
(41)  0985050003
SELF LOCKING NUT DIN0985-M 5
42
(42)  45001070000
BRAKE CABLE CLAMP RSGU 9/12
43
(43)  0025050206
HH COLLAR SCREW M5X20 TX30
HH COLLAR SCREW M 5X20 WS=8
98
(98)  00050000924
HANDLEBAR SUPPORT KIT 50 SX
99
(99)  7550013
FORKOIL EBH16 SAE 7.5
Part number Description Unit Price Incl. Tax Qty
# 1

45101000444

FORK CPL. SX JUN MARZ. 2002
Contact
# 5

7501476A

TOP FORK PLATE
# 6

0912080303

AH SCREW DIN0912-M 8X30
# 8

7504212AC

PLUG CAP
# 9

7528010

O-RING
Contact
# 11

7518031

PRE LOAD BUSH L=55MM 2002
Contact
# 12

75141214

SPRING 2, 5N/MM
# 12

75141169

SPRING 2N/MM
Contact
# 13

7533297

DUST SEAL
Contact
# 14

7523264

STOP RING
Contact
# 15

7528230

OIL SEAL 32/42/6, 5-9, 5
Contact
# 16

7522166AA

WASHER D42X32, 5X1, 5
Contact
# 17

7524157

PISTON RING D32
Contact
# 18

7803936/A

PISTON ROD REBOUND JUNIOR 02
Contact
# 18

7803938/A

PISTON ROD COMPRESSION JUN. 02
Contact
# 19

75141015

REBOUND SPRING
Contact
# 20

75031570A

SLIDER L/S 50 LC 2002
Contact
# 21

75031570A/R

SLIDER CPL. L/S 50LC 2002
Contact
# 22

7522225

WASHER 14X8X1, 5
# 25

77051124

BOT. FORK PLATE CPL. MINI/JUN
Contact
# 26

7708247/R

FORK TUBE R/S MINI/JUN. 02
Contact
# 27

7708248/R

FORK TUBE L/S MINI/JUN. 02
Contact
# 28

7512068

FOOT BUFFER
# 29

75031571A

SLIDER R/S 50 LC 2002
Contact
# 31

75031571A/R

SLIDER CPL. R/S 50LC 2002
Contact
# 34

50301036000

STEER.HEAD SCREW M20X1, 5 WS=27
Contact
# 35

45101081100

STEER.STEM B.CPL.50 SXR 2003 (45101036000, 45101081200)
STEER.STEM B.CPL.50 SXR 2003
Contact
# 36

0015080303

0025080306
HH COLLAR SCREW M8X30
HH COLLAR SCREW M 8X30 WS=10
# 37

0912100250

0032100256S
AH-COLLAR SCREW M10X25 ISA45
AH SCREW DIN6912-M10X25, 10.9
# 38

50301038000

HANDLEBAR CLAMP D=22MM 2001
# 39

45101039000

HANDLEBAR SUPPORT D=22MM 2001
# 40

7547325

STICKER LEFT SIDE MARZOCCHI
Contact
# 41

0985050003

SELF LOCKING NUT DIN0985-M 5
# 42

45001070000

BRAKE CABLE CLAMP RSGU 9/12
# 43

0015050203

0025050206
HH COLLAR SCREW M5X20 TX30
HH COLLAR SCREW M 5X20 WS=8
# 98

00050000924

HANDLEBAR SUPPORT KIT 50 SX
Contact
# 99

7550013

FORKOIL EBH16 SAE 7.5
Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
