SHOCK ABSORBER (PARTS)

SHOCK ABSORBER (PARTS) FOR KTM 505 SX ATV 2010

SWINGARM

Item numbers

MONOSHOCK LOWER PART

46180654SA6

Contact

MONOSHOCK UPPER PART

46180728SA

Contact

COMPRESSION CPL.

50180213S6

109,44 £

Unit Price Incl. Tax

LOCK NUT SHOCK M54X1, 5

46180766

28,62 £

Unit Price Incl. Tax

ADJUSTMENT NUT SHOCK M54X1, 5

46180765

34,32 £

Unit Price Incl. Tax

SPRING 100-55

91010297S

118,44 £

Unit Price Incl. Tax

WASHER 58, 6X73, 6X1, 5

50180410

2,46 £

Unit Price Incl. Tax

SPRING RETAINER 52, 5X76X5

46180787

24,36 £

Unit Price Incl. Tax

BALL JOINT BEARING KIT TOP 12MM

R12012

R12012T

29,40 £

Unit Price Incl. Tax

DISTANCE BUSH 12X15/18/24, 5X10, 5
DISTANCE BUSH 12X15/18/24, 5X10

46180007

8,04 £

Unit Price Incl. Tax

COPPER WASHER 55X2 RVS

46180513

Contact

REPAIR KIT

R15007

48,42 £

Unit Price Incl. Tax

ROUND-WIRE SNAP RING 49X1, 8

46810010

3,30 £

Unit Price Incl. Tax

(59) 74-200 D 11, 25 ORANGE

91010291

Contact

SPRING 78-200

91010298S

118,44 £

Unit Price Incl. Tax

SPRING 70-200

91010305S

118,44 £

Unit Price Incl. Tax

SPRING RETAINER D74

46180512

Contact

HS CYLINDER-HEAD SCREW R1/8 L8

50180095

4,50 £

Unit Price Incl. Tax

SHOCK ABSORBER FLUID SAF 1579A

50180342

Contact

RUBBER CAP DO NOT OPEN 22X5, 5 NBR
RUBBER CAP DO NOT OPEN 22X5, 5

46811208

4,26 £

Unit Price Incl. Tax

PLUG SCREW M5X6 CPL.

36120151

36120151ST

3,90 £

Unit Price Incl. Tax

O-RING 5, 28X1, 78 HNBR70 RED

46810893

S208600003000FB

1,20 £

Unit Price Incl. Tax

STICKER WP CLEAR 35X55

52000086

5,22 £

Unit Price Incl. Tax

STICKER WARNING 27X55

52000012

Contact

PISTON RING 43, 95X45, 95X8

46811206

15,48 £

Unit Price Incl. Tax

BUMP STOP RUBBER W-60 D18

50180120

Contact

SEPARATION BUSH 17X12X18

46180339

Contact

REBOUND DISC H=0

46180179

Contact

SEALHOLDER 46X28 CPL.

46180669S

29,04 £

Unit Price Incl. Tax

O-RING 37X, 82X1, 78 VITON70 GREEN
O-RING 37X, 82X1, 78 VITON70 GRE

46810035

3,30 £

Unit Price Incl. Tax

PISTON ROD NUT M10X1

46180356

10,98 £

Unit Price Incl. Tax

PISTON 5X4, 5X/6X6

46180441

34,74 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
