CARBURETOR

CLUTCH FOR KTM 450 SX ATV 2009

GEARBOX MAIN SHAFT

(1) 83532001144

OUTER CLUTCH CPL.
OUTER CLUTCH CPL. 08

(2) 77332002200

INNER CLUTCH HUB 08

(3) 77332003000

PRESSURE PLATE

(9) 77332010000

INTERMEDI. DISC STEEL

(9) 77332010000

INTERMEDI. DISC STEEL

(10) 77332011010

CLUTCH-KIT 450/505 SX-F 07-13

(11) 77332011000

LINING DISC 2,7MM

(11) 77332011000

LINING DISC 2,7MM

(13) 77332015100

INNER RING

(18) 77332018000

RETAINING PLATE

(19) 0936181505

HEXAGON NUT DIN0936-M18X1,5 R.

(20) 77332017100

WASHER 21,7X38X4 07

(23) 83532023026

PRIMARY GEAR

(24) 83530055010

DRIVE WHEEL

(29) 0770380020

O-RING 38,00X2,00 NBR 70 SH

(30) 77332061044

OUTPUT CYLINDER CPL.

(36) 77332066000

PISTON CPL.

(50) 50232050000

WASHER 6,2X18X2

(53) 77332054100

PUSH ROD 07

(54) 77332057100

PRESSURE PIECE

(55) 77332057144

PRESSURE PIECE CPL.

(71) 0025060256

HH COLLAR SCREW M6X25 TX30

(71) 0025060256

HH COLLAR SCREW M6X25 TX30

(71) 0025060256

HH COLLAR SCREW M6X25 TX30

(75) 50329050000

VENT INJEKTION HYDR. CLUTCH

(80) 77332005000

CLUTCH SPRING

(80) 77332005000

CLUTCH SPRING

(87) 42013226000

CU-SEAL RING DIN7603-10X16X1

(88) 62513020000

BLEEDER SCREW CPL. 05

(95) 56532095000

NEEDLE BEARING K26X30X22ZW.KSE

(97) 54637097200

AXIAL NEEDLE BEARING AXK 1226

(98) 54637098200

AXIAL WASHER AS1226 12X26X1

(99) 0993012000

CIRCLIP DIN7993-RW12

	Part number	Description	Qty
# 1	83532001044	OUTER CLUTCH CPL. OUTER CLUTCH CPL. 08	Contact	0,00 £
# 2	77332002200	INNER CLUTCH HUB 08	Contact	0,00 £
# 3	77332003000	PRESSURE PLATE	60,00 £
# 9	77332010000	INTERMEDI. DISC STEEL	9,36 £
# 10	77332011010	CLUTCH-KIT 450/505 SX-F 07-13	228,60 £
# 11	77332011000	LINING DISC 2, 7MM	15,54 £
# 13	77332015100	INNER RING	22,74 £
# 18	77332018000	RETAINING PLATE	4,92 £
# 19	0936181505	HEXAGON NUT DIN0936-M18X1, 5 R.	3,54 £
# 20	77332017100	WASHER 21, 7X38X4 07	5,58 £
# 23	83532023026	PRIMARY GEAR	Contact	0,00 £
# 24	83530055010	DRIVE WHEEL	Contact	0,00 £
# 29	0770380020	O-RING 38, 00X2, 00 NBR 70 SH	1,38 £
# 30	77332061044	OUTPUT CYLINDER CPL.	141,60 £
# 36	77332066000	PISTON CPL.	46,56 £
# 50	50232050000	WASHER 6, 2X18X2	2,88 £
# 53	77332054100	PUSH ROD 07	19,92 £
# 54	77332057100	PRESSURE PIECE	19,92 £
# 55	77332057144	PRESSURE PIECE CPL.	24,36 £
# 71	0025060256	HH COLLAR SCREW M6X25 TX30	1,62 £
# 75	50329050000	VENT INJEKTION HYDR. CLUTCH	Contact	0,00 £
# 80	77332005000	CLUTCH SPRING	6,60 £
# 87	42013226000	CU-SEAL RING DIN7603-10X16X1	1,44 £
# 88	62513020000	BLEEDER SCREW CPL. 05	16,80 £
# 95	56532095000	NEEDLE BEARING K26X30X22ZW.KSE	13,20 £
# 97	54637097200	AXIAL NEEDLE BEARING AXK 1226	6,66 £
# 98	54637098200	AXIAL WASHER AS1226 12X26X1	2,88 £
# 99	0993012000	CIRCLIP DIN7993-RW12	1,14 £

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
