IGNITION SWITCH

EVAPORATIVE CANISTER FOR KTM 390 DUKE BLACK ABS 2014

BRAKE ANTIBLOCK SYSTEM ABS

(1) 90207016000

HOSE

(2) 59415001100

EVAPORATIVE CANISTER 08
TANK CANISTER

(3) 90203001053

LOCATOR CAP CANISTER

(4) 90607029001

STRAP CANISTER

(5) 90203001051

BRACKET CANISTER MTG

(6) J025060109

HH-COLLAR SCREW M6X10 SW8

(7) 90607030000

FUEL TANK VENT VALVE

(9) 90203001050

BRACKET PURGE VALVE

(10) 90203001054

BRACKET CANISTER HOSE ROUTING

(11) J025060183

HH COLLAR SCREW M6X18 SW10

(12) 90615003000

COLLAR 8X6X7

(13) 90615002000

GROMMET 15,5X8X8,1

(14) 90607017002

CLAMP D9

(14) 90607017002

CLAMP D9

(14) 90607017002

CLAMP D9

(15) 90607016300

HOSE

(16) 90207016002

TUBE PURGE VALVE TO CONNECTOR

(17) 90207016004

CONNECTOR TUBE EVAP

(18) 90207016003

HOSE

(19) 90607017001

SPRING BAND CLAMP 15X10

(19) 90607017001

SPRING BAND CLAMP 15X10

(20) 90107018011

CLAMP 10MM

(20) 90107018011

CLAMP 10MM

(20) 90107018011

CLAMP 10MM

	Part number	Description	Qty
# 1	90207016000	HOSE	15,78 £
# 2	90207027001 59415001100	EVAPORATIVE CANISTER 08 TANK CANISTER	35,58 £
# 3	90203001053	LOCATOR CAP CANISTER	5,40 £
# 4	90607029001	STRAP CANISTER	6,06 £
# 5	90203001051	BRACKET CANISTER MTG	6,30 £
# 6	J025060109	HH-COLLAR SCREW M6X10 SW8	1,44 £
# 7	90607030000	FUEL TANK VENT VALVE	55,26 £
# 9	90203001050	BRACKET PURGE VALVE	Contact	0,00 £
# 10	90203001054	BRACKET CANISTER HOSE ROUTING	5,40 £
# 11	J025060183	HH COLLAR SCREW M6X18 SW10	1,44 £
# 12	90615003000	COLLAR 8X6X7	2,52 £
# 13	90615002000	GROMMET 15, 5X8X8, 1	2,52 £
# 14	90607017002	CLAMP D9	1,56 £
# 15	90607016300	HOSE	15,78 £
# 16	90207016002	TUBE PURGE VALVE TO CONNECTOR	11,22 £
# 17	90207016004	CONNECTOR TUBE EVAP	6,60 £
# 18	90207016003	HOSE	11,22 £
# 19	90607017001	SPRING BAND CLAMP 15X10	1,86 £
# 20	90107018011	CLAMP 10MM	1,86 £

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
