SHOCK PRO LEVER LINKAGE FOR KTM RC 250 R 2013

SWINGARM

(1) B3304083000

LINK

(2) 69004096000

QUAD-RING 17,12X2,62X2,62 NBR

(3) 0760182442

SHAFT SEAL RING 18X24X4

(4) B3304087000

BEARING F. LINK DL18/16

(5) 69004085000

BEAR. BUSH. CONN. ROD BELOW 08

(6) B3304086001

SPACER - SCREW/SWING ARM/LINK

(7) 69004094000

HH COLLAR SCREW M10X56 WS13 08

(7) 69004094000

HH COLLAR SCREW M10X56 WS13 08

(8) B3304085000

ADAPTER BUSH

(9) B3304083010

OIL SEAL

(10) B3304083050

BEARING DL17/12 (17X23X12)

(11) B3304084000

INNER BEARING BUSH

(12) 69004089000

HH COLLAR SCREW M10X42 WS13 08

(13) B3304081000

PULLROD

(14) GP304131100

SLEEVE FRAME - DRAG LINK

(15) GP3041490100

BEARING NK 14/16

(16) B3303013000

WASHER

(17) 69004095100

RIVET NUT M10
ADAPTOR NUT M10

	Part number	Description	Qty
# 1	B3304083000	LINK	322,50 £
# 2	69004096000	QUAD-RING 17, 12X2, 62X2, 62 NBR	2,28 £
# 3	0760182442	SHAFT SEAL RING 18X24X4	4,08 £
# 4	B3304087000	BEARING F. LINK DL18/16	Contact	0,00 £
# 5	69004085000	BEAR. BUSH. CONN. ROD BELOW 08	11,94 £
# 6	B3304086001	SPACER - SCREW/SWING ARM/LINK	3,54 £
# 7	69004094000	HH COLLAR SCREW M10X56 WS13 08	7,32 £
# 8	B3304085000	ADAPTER BUSH	4,74 £
# 9	B3304083010	OIL SEAL	10,86 £
# 10	B3304083050	BEARING DL17/12 (17X23X12)	23,10 £
# 11	B3304084000	INNER BEARING BUSH	48,90 £
# 12	69004089000	HH COLLAR SCREW M10X42 WS13 08	7,32 £
# 13	B3304081000	PULLROD	Contact	0,00 £
# 14	GP304131100	SLEEVE FRAME - DRAG LINK	38,16 £
# 15	GP3041490100	BEARING NK 14/16	10,86 £
# 16	B3303013000	WASHER	6,36 £
# 17	69004095000 69004095100	RIVET NUT M10 ADAPTOR NUT M10	4,56 £

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SHOCK PRO LEVER LINKAGE of your KTM RC 250 R of 2013. Let us know if you have any questions.
