VALVES

TIMING FOR KTM 250 SX-F ROCZEN REPLICA 2012

CYLINDER HEAD

Item numbers

TIMING CHAIN GUIDE TOP 05

77036004000

11,22 £

Unit Price Incl. Tax

SPACER BUSHING GUIDE RAIL ?05
SPACER BUSHING GUIDE RAIL ´05

77036004050

5,16 £

Unit Price Incl. Tax

CAMSHAFT GEAR SCREW 08

77036012100

5,88 £

Unit Price Incl. Tax

CAMSHAFT GEAR

77036011300

81,12 £

Unit Price Incl. Tax

BALL BEARING 6004 NR C3 ?05
BALL BEARING 6004 NR C3 ´05

0625060043

10,62 £

Unit Price Incl. Tax

CAMSHAFT INTAKE CPL.

77136009144

219,90 £

Unit Price Incl. Tax

NEEDLE ROOLER DIN5402 NRB 4X6

0402040600

1,44 £

Unit Price Incl. Tax

CAMSHAFT EXHAUST CPL.

77136010144

228,48 £

Unit Price Incl. Tax

AUTO DECOMPRESSION SHAFT

77036015100

17,10 £

Unit Price Incl. Tax

AUTO DECO WEIGHT

77036016100

19,80 £

Unit Price Incl. Tax

SPRING FOR AUTO DECOMPR. 05

77036017000

5,16 £

Unit Price Incl. Tax

BEARING PIN AUTODECO

77036019100

14,34 £

Unit Price Incl. Tax

TIMING CHAIN GUIDE 05

77036001000

14,46 £

Unit Price Incl. Tax

BUSHING SCREW 06

77036001160

5,16 £

Unit Price Incl. Tax

SEAL RING CU DIN7603- 8X12X1

0603082121

1,32 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X25 TX30

0025060256

1,74 £

Unit Price Incl. Tax

SPACER BUSHING 6, 1X8, 2X13, 1

59036001050

3,00 £

Unit Price Incl. Tax

SECURING PROTECTION ?05
SECURING PROTECTION ´05

77036005000

7,56 £

Unit Price Incl. Tax

TIMING CHAIN TENSIONER ?05
TIMING CHAIN TENSIONER ´05

77036002000

14,46 £

Unit Price Incl. Tax

SPACER BUSHING 6.1X8.2X9.1 05

77036001050

2,64 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X40 TX30

0025060406

1,74 £

Unit Price Incl. Tax

CHAIN ADJUSTER HOLDING BOLT

78036008100

17,10 £

Unit Price Incl. Tax

CU SEAL-RING DIN7603 A24X29X2

0603242920

1,56 £

Unit Price Incl. Tax

CHAIN ADJUSTER HYD. 05

77036003000

67,62 £

Unit Price Incl. Tax

O-RING 18.00X2.00 NBR70

0770180020

1,26 £

Unit Price Incl. Tax

TIMING VALVE JACKSHAFT 08

77036072100

85,86 £

Unit Price Incl. Tax

STOP DISK 18, 2X30X1 05

77036073000

2,34 £

Unit Price Incl. Tax

WOODRUFF KEY DIN6888-3X3, 7

0888030037

0,90 £

Unit Price Incl. Tax

TIMING VALVE TWIN WHEEL

77036076200

94,02 £

Unit Price Incl. Tax

TIMING CHAIN 108 ROLLS

77036013100

80,40 £

Unit Price Incl. Tax

BALL BEARING 6203 JR2 C3

0625062035

10,62 £

Unit Price Incl. Tax

NEEDLE BEAR.HK1812 18/24/12 05

0618182412

7,56 £

Unit Price Incl. Tax

NEEDLE ROL.DIN5402 NRB 3X17, 8

0402031780

1,44 £

Unit Price Incl. Tax

WATER PUMP ROTOR 05

77035055000

7,92 £

Unit Price Incl. Tax

CIRCLIP DIN0471-10X1

0471100010

1,20 £

Unit Price Incl. Tax

SHAFT SEAL RING 12X30X7 PTFE

0760123073

5,22 £

Unit Price Incl. Tax

MOLDED RING WATER PUMP 05

77035053000

6,90 £

Unit Price Incl. Tax

WATER PUMP COVER 05

77035052000

39,84 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X35 TX30

0025060356

1,74 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X20 TX30

0025060206

1,74 £

Unit Price Incl. Tax

CU-SEAL RING DIN7603-6X10X1

0603061001

1,32 £

Unit Price Incl. Tax

O-RING 10.00X1.00 NBR70

0770010010

1,26 £

Unit Price Incl. Tax

HOLDING BOLT

77336008010

5,88 £

Unit Price Incl. Tax

WATER PUMP REP. KIT 06-13

77035055010

30,24 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
