HANDLEBAR / CONTROLS

FRAME FOR KTM 1290 SUPER DUKE R EVO BLACK 2023

SIDE / MAIN STAND

Item numbers

FRAME 617VA

61703001200EB

2 073,18 £

Unit Price Incl. Tax

ENGINE HANGER FRONT LEFT

61703005000C1

55,02 £

Unit Price Incl. Tax

ENGINE HANGER FRONT RIGHT

61703006000C1

55,02 £

Unit Price Incl. Tax

ENGINE HANGER REAR LEFT

61703007000C1

55,02 £

Unit Price Incl. Tax

ENGINE HANGER REAR RIGHT

61703008000C1

55,02 £

Unit Price Incl. Tax

HH COLLAR SCREW M10X24 ISA45 S

0035100249S

5,22 £

Unit Price Incl. Tax

ONE-WAY SCREW 617

61711064000

6,00 £

Unit Price Incl. Tax

CLIP NUT M6

54603048100

3,36 £

Unit Price Incl. Tax

CLIP NUT M5

69008021080

2,82 £

Unit Price Incl. Tax

SUPPORT ABS-PIPE D7, 5

61342046000

5,70 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X10 TX30

0025060106

1,74 £

Unit Price Incl. Tax

CONTACT WASHER M6 VSV-K6

58411098100

2,34 £

Unit Price Incl. Tax

HH COLLAR SCREW M6X16 TX30

0025060166

1,74 £

Unit Price Incl. Tax

FRONT FOOTPEG BRACKET LEFT

61703038000C1

136,68 £

Unit Price Incl. Tax

FRONT FOOTPEG LEFT

61703040000C1

58,38 £

Unit Price Incl. Tax

SHCS M8X20 TX45

0035080206S

3,36 £

Unit Price Incl. Tax

FOOTPEG BOLT

61703043000

11,10 £

Unit Price Incl. Tax

SPRING FOOTREST FRONT

61703042000

5,16 £

Unit Price Incl. Tax

FRONT FOOTPEG BRACKET RIGHT

61703039000C1

136,68 £

Unit Price Incl. Tax

FRONT FOOTPEG RIGHT

61703041000C1

58,38 £

Unit Price Incl. Tax

FOOTREST BOTTOM FIXING NUT

61703045010

13,32 £

Unit Price Incl. Tax

SUBFRAME RIGHT BLACK

61703002020C1

361,74 £

Unit Price Incl. Tax

FUEL TANK BRIDGE

61703002030C1

63,18 £

Unit Price Incl. Tax

REAR FOOTPEG BRACKET LEFT

61703048000C1

154,32 £

Unit Price Incl. Tax

REAR FOOTPEG BRACKET RIGHT

61703049000C1

154,32 £

Unit Price Incl. Tax

REAR FOOTPEG LEFT CMPL.

61703050033C1

58,38 £

Unit Price Incl. Tax

REAR FOOT PEG BOLT

61703053000

11,10 £

Unit Price Incl. Tax

REAR FOOTPEG RIGHT CMPL.

61703051033C1

58,38 £

Unit Price Incl. Tax

SCREW, RESERVOIR

69013099150

3,72 £

Unit Price Incl. Tax

SUBFRAME LEFT BLACK

61703002010C1

361,74 £

Unit Price Incl. Tax

ISA COLLAR SCREW, M8X35, MK-ISA45
ISA COLLAR SCREW, M8X35, MK-IS

0000350803500S

3,36 £

Unit Price Incl. Tax

HEX SCREW W.INTERN.TORX W.COLL.M8X60 ISA
HEX SCREW W.INTERN.TORX W.COLL

0035080606S

3,36 £

Unit Price Incl. Tax

MOUNTING FLANGE TOP LEFT BLACK

61703002054C1

34,32 £

Unit Price Incl. Tax

MOUNTING FLANGE TOP RIGHT BLACK
MOUNTING FLANGE TOP RIGHT BLAC

61703002055C1

34,32 £

Unit Price Incl. Tax

CROSS RIB, BLACK

61703002040C1

146,10 £

Unit Price Incl. Tax

HH COLLAR SCREW M5X10 TX30

0025050106

1,74 £

Unit Price Incl. Tax

ISA COLLAR SCREW M8X25 ISA45

0035080256S

3,36 £

Unit Price Incl. Tax

TETHER, PASSENGER

61707048170

23,82 £

Unit Price Incl. Tax

PLUG SMALL

61703288000

3,48 £

Unit Price Incl. Tax

PLUG, SMALL

61703188000

3,96 £

Unit Price Incl. Tax

PLUG, LARGE

61703088000

3,96 £

Unit Price Incl. Tax

SPACING TUBE IGNITION LOCK

61711065000

5,40 £

Unit Price Incl. Tax

CABLE TIE WITH FOOT SECTION

0330000520000

3,48 £

Unit Price Incl. Tax

FRAME COVER

61703083000

3,84 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
