CYLINDER

CYLINDER FOR KTM 125 EXC MARZOCCHI/OHLINS 1997

CRANKSHAFT / PISTON

Item numbers

CYLINDER CPL.WITH FLANGE '94

50230005244

Contact

DOWEL 9, 8 X7X10

49030090000

49030090100

1,98 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X25

0912060253

1,26 £

Unit Price Incl. Tax

RETAINING PLATE

51005074000

2,34 £

Unit Price Incl. Tax

CYLINDER BASE GASKET 0, 05MM

50230030005

7,08 £

Unit Price Incl. Tax

CYLINDER BASE GASKET 0, 10MM

50230030010

Contact

CYLINDER BASE GASKET 0, 15MM

50230030015

Contact

CYLINDER BASE GASKET 0, 30MM

50230030030

Contact

CYLINDER BASE GASKET 0, 50MM

50230030050

2,82 £

Unit Price Incl. Tax

CYLINDER BASE GASKET 0, 75MM

50230030075

3,66 £

Unit Price Incl. Tax

STUD M8X37

50230043000

Contact

COLLAR NUT M8

49030028000

1,98 £

Unit Price Incl. Tax

HH PLUG M10X1 WS13

54630021000

5,94 £

Unit Price Incl. Tax

SEALING RING DIN 7603 10X14X1

58038032010

0603100141

1,32 £

Unit Price Incl. Tax

CYLINDER HEAD GASKET

50230036500

7,08 £

Unit Price Incl. Tax

SILICON O-RING 60X2

50230095000

Contact

CYLINDER HEAD '94

50230006200

Contact

CU-SEAL RING DIN7603- 7, 3X12X1

50230032010

0603070121

1,32 £

Unit Price Incl. Tax

CYL. HEAD BOLT M 7X40 WS=10

50030079000

5,64 £

Unit Price Incl. Tax

CU-SEAL RING DIN7603-6X10X1

58036065000

0603061001

1,32 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X 8

0912060083

1,26 £

Unit Price Incl. Tax

GASKET

54435037000

Contact

CONNECTING TUBE 125/IV

50235006000

Contact

SPRING WASHER DIN 137 B - 6

0137060000

0137060003

0,90 £

Unit Price Incl. Tax

AH SCREW DIN0912-M 6X20

0912060203

1,26 £

Unit Price Incl. Tax

HOSE CLIP 18-29

10001020000

0310000902900

2,58 £

Unit Price Incl. Tax

PREFORMED HOSE 18X3, 5-90 DG

50235025700

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER of your KTM 125 EXC MARZOCCHI/OHLINS of 1997. Let us know if you have any questions.
