CYLINDER

CRANKSHAFT / PISTON FOR KTM 1090 ADVENTURE R 2017

SYSTÈME D'AIR SECONDAIRE

Item numbers

CONNECTING ROD SCREW MJ10X1

61230015100

15,30 £

Unit Price Incl. Tax

NEEDLE ROL.DIN5402 NRB 4X9, 8

0402040980

1,44 £

Unit Price Incl. Tax

CONNECTING ROD CPL. 125MM

60630013000

237,72 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH RED

612300151101

21,90 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH BLUE

612300151102

21,90 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH YELLOW

612300151103

21,90 £

Unit Price Incl. Tax

WOODRUFF KEY DIN 6888 4X5X13

0888040050

0,90 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH RED 08

612300820001

25,56 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH BLUE 08

612300820002

25,56 £

Unit Price Incl. Tax

SPLIT BEAR. BUSH YELLOW 08

612300820003

25,56 £

Unit Price Incl. Tax

CRANKSHAFT CPL.

60630018000

1 010,76 £

Unit Price Incl. Tax

BUSHING BOWL 28X32X13 03

60030026010

18,24 £

Unit Price Incl. Tax

HH-NUT M33X1, 5 L/S WS46 03

60032009050

12,24 £

Unit Price Incl. Tax

WASHER 33, 2X46X2 03

60032009040

5,04 £

Unit Price Incl. Tax

PISTON D103 CPL. GR. I

60630007100I

364,08 £

Unit Price Incl. Tax

PISTON D103 CPL. GR. II

60630007100II

364,08 £

Unit Price Incl. Tax

PISTON PIN

61330033000

34,68 £

Unit Price Incl. Tax

CIRCLIP LC4 07

75030074000

6,48 £

Unit Price Incl. Tax

PRIMARY GEAR

61230055000

144,48 £

Unit Price Incl. Tax

DRIVE WHEEL BALANCER SHAFT 08

61230056000

121,74 £

Unit Price Incl. Tax

PISTON RING KIT D103

60630031044

75,18 £

Unit Price Incl. Tax

PISTON KIT GR. I 1050 ADV

60630007110I

428,10 £

Unit Price Incl. Tax

PISTON KIT GR. II 1050 ADV

60630007110II

428,10 £

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
